22 Gallon/ 83 Liter, Flammable Chemical Storage Cabinet

SKU: # ZYC0022

Safety Chemicals Storage Cabinet System

Flammable Storage Cabinet, 22 gallon/83 L with two doors and two shelves.  Protect workers, reduce fire risks, and improve productivity by storing flammable fuels and chemicals in code-compliant safety cabinets. Designed to meet OSHA and NFPA 30 standards, ZOYET chemical storage cabinets are constructed of sturdy 18-gauge (1-mm) thick double-wall, welded steel with 1-1/2-in (38-mm) of insulating air space for fire resistance. Fail-safe closing mechanism ensures three-point stainless steel bullet latching system works every time. Reflective warning labels are highly visible under fire conditions or during power outages when illuminated with a flashlight.

Galvanized steel shelves direct spills to back and bottom of a leakproof sump. They adjust on 3-in (76-mm) centers for versatile storage. Cabinets also feature a leakproof 2-in (51-mm) bottom sump, dual vents with flame arresters, four adjustable self-leveling feet, grounding connector and trilingual warning label. Durable lead-free epoxy/polyester powder-coat finish provides excellent chemical resistance.

Capacity Gallons/Liters

22 Gallon/ 83 Liter

Sump Capacity Gallons/Liters

2.5 Gallon/ 9.5 Liter, Leakproof bottom sump,

Number of Doors

1 Door, Manual

Adjustable Shelves

2 Shelves

External Dimension, L x D x H

590mm x 460mm x 1650mm

Internal Dimension, L x D x H

500mm x 375mm x 1540mm

Ship Weight

85 Kg


OSHA CFR29 1910.106/ NFPA code 30 compliance/ CE Mark/ EN14470-1

Thickness, Double Wall

1mm thick, 38mm air space

Door Locks

Three point latching door, 2 locks

Vent Holes

2 Vent holes, 62-65mm diameter

Leg & Grounding

Adjustable leg and grounding wires,

Ventilation Compatibility

Compatible to Erlab Venticap 502 Filtration Box to achieve more than 10 air change per hour

Colour coding & Alert Sign

Yellow colour with "Flammable" Alert Sign
